Hex Bolt Dimensions
|
Hex Bolt Dimensions
|
||||||||
|
Basic Product Diameter
|
Full-Size Body Diameter
|
Width Across Flats
|
Width Across Corners
|
Head Height
|
Thread Length
|
Thread Length
|
||
|
Max
|
Min
|
Max
|
Min
|
Up to 6in
|
Over 6 in
|
|||
|
1/4
|
.26
|
.237
|
7/16
|
.505
|
0.484
|
11/64
|
0.75
|
1.00
|
|
5/16
|
.324
|
.298
|
1/2
|
.577
|
0.552
|
7/32
|
0.88
|
1.13
|
|
3/8
|
.388
|
.360
|
9/16
|
.650
|
0.62
|
1/4
|
1.00
|
1.25
|
|
7/16
|
.452
|
.421
|
5/8
|
.722
|
0.687
|
19/64
|
1.13
|
1.38
|
|
1/2
|
.515
|
.482
|
3/4
|
.866
|
0.826
|
11/32
|
1.25
|
1.50
|
|
5/8
|
.642
|
.605
|
15/16
|
1.083
|
1.033
|
27/64
|
1.50
|
1.75
|
|
3/4
|
.768
|
.729
|
1-1/8
|
1.299
|
1.24
|
1/2
|
1.75
|
2.00
|
|
7/8
|
.895
|
.852
|
1-5/16
|
1.516
|
1.447
|
37/64
|
2.00
|
2.25
|
|
1
|
1.022
|
.976
|
1-1/2
|
1.732
|
1.653
|
43/64
|
2.25
|
2.50
|
|
1-1/8
|
1.149
|
1.098
|
1-11/16
|
1.949
|
1.859
|
3/4
|
2.50
|
2.75
|
|
1-1/4
|
1.277
|
1.223
|
1-7/8
|
2.165
|
2.066
|
27/32
|
2.75
|
3.00
|
|
1-3/8
|
1.404
|
1.345
|
2-1/16
|
2.382
|
2.273
|
29/32
|
3.00
|
3.25
|
|
1-1/2
|
1.531
|
1.47
|
2-1/4
|
2.598
|
2.48
|
1
|
3.25
|
3.50
|
|
1-3/4
|
1.785
|
1.716
|
2-5/8
|
3.031
|
2.893
|
1-5/32
|
3.75
|
4.00
|
|
2
|
2.039
|
1.964
|
3
|
3.464
|
3.306
|
1-11/32
|
4.25
|
4.50
|
|
2-1/4
|
2.305
|
2.214
|
3-3/8
|
3.897
|
3.719
|
1-1/2
|
4.75
|
5.00
|
|
2-1/2
|
2.559
|
2.461
|
3-3/4
|
4.33
|
4.133
|
1-21/32
|
5.25
|
5.5
|
|
2-3/4
|
2.827
|
2.711
|
4-1/8
|
4.763
|
4.546
|
1-13/16
|
5.75
|
6.00
|
|
3
|
3.081
|
2.961
|
4-1/2
|
5.196
|
4.959
|
2
|
6.25
|
6.50
|
|
3-1/4
|
3.335
|
3.21
|
4-7/8
|
5.629
|
5.372
|
2-3/16
|
6.75
|
7.00
|
|
3-1/2
|
3.589
|
3.461
|
5-1/4
|
6.062
|
5.786
|
2-5/16
|
7.25
|
7.50
|
|
3-3/4
|
3.858
|
3.726
|
5-5/8
|
6.495
|
6.198
|
2-1/2
|
7.75
|
8.00
|
|
4
|
4.111
|
3.975
|
6
|
6.928
|
6.612
|
2-11/16
|
8.25
|
8.50
|
Nut dimension
| Nominal | Thread. | Nut Diameter | Nut | |
| Size | Pitch | Major | Minor Max – min |
Thick (Zn) |
| M6 | 0,75 | 6,000 | 5,378 – 5,188 | 5,00 |
| M8 | 1,00 | 8,000 | 7,153 – 6,917 | 6,50 |
| M10 | 1,25 | 10,000 | 8,912 – 8,647 | 8,00 |
| M12 | 1,25 | 12,000 | 10,912 – 10,647 | 10,00 |
| M16 | 1,50 | 16,000 | 14,676 – 14,376 | 13,00 |
| M20 | 1,50 | 20,000 | 18,676 – 18,376 | 16,00 |
| M24 | 2,0 | 24,000 | 22,210 – 21,835 | 19,00 |
| M30 | 2,0 | 30,000 | 28,210 – 27,835 | 24,00 |
| M36 | 3,0 | 36,00 | 33,252 – 32,752 | 29,00 |
Washer Dimensions
| Nominal | Washer Diameter | Washer Thickness | ||
| Size | Internal max – min |
External max – min |
Thick max – min |
Thin |
| M3 | 3,4 – 3,2 | 7,0 – 6,7 | 0,6 – 0,4 | – |
| M4 | 4,5 – 4,3 | 9,0 – 8,7 | 0,9 – 0,7 | – |
| M5 | 5,5 – 5,3 | 10,0 – 9,7 | 1,1 – 0,9 | – |
| M6 | 6,7 – 6,4 | 12,5 – 12,1 | 1,8 – 1,4 | 0,9 – 0,7 |
| M8 | 8,7 – 8,4 | 17,0 – 16,6 | 1,8 – 1,4 | 1,1 – 0,9 |
| M10 | 10,9 – 10,5 | 21,0 – 20,5 | 2,2 – 1,8 | 1,45 – 1,05 |
| M12 | 13,4 – 13,0 | 24,0 – 23,5 | 2,7 – 2,3 | 1,8 – 1,4 |
| M16 | 17,4 – 17,00 | 30,0 – 29,5 | 3,3 – 2,7 | 2,2 – 1,8 |
| M20 | 21,5 – 21,0 | 37,0 – 36,2 | 3,3 – 2,7 | 2,2 – 1,8 |
| M24 | 25,5 – 25,0 | 44,0 – 43,2 | 4,3 – 3,7 | 2,7 – 2,3 |
| M30 | 31,6 – 31,0 | 56,0 – 55,0 | 4,3 – 3,7 | 2,7 – 2,3 |
| M36 | 37,6 – 37,0 | 66,0 – 65,0 | 5,6 – 4,4 | 3,3 – 2,7 |
